Bandgap engineering of two-dimensional semiconductor materials (from nature.com)

A. Chaves, J. G. Azadani, Hussain Alsalman, D. R. da Costa, R. Frisenda, A. J. Chaves, Seung Hyun Song, Y. D. Kim, Daowei He, Jiadong Zhou, A. Castellanos-Gomez, F. M. Peeters, Zheng Liu, C. L. Hinkle, Sang-Hyun Oh, Peide D. Ye, Steven J. Koester, Young Hee Lee, Ph. Avouris, Xinran Wang & Tony Low

npj 2D Materials and Applications volume 4, Article number: 29 (2020)

Abstract

Semiconductors are the basis of many vital technologies such as electronics, computing, communications, optoelectronics, and sensing. Modern semiconductor technology can trace its origins to the invention of the point contact transistor in 1947. This demonstration paved the way for the development of discrete and integrated semiconductor devices and circuits that has helped to build a modern society where semiconductors are ubiquitous components of everyday life. A key property that determines the semiconductor electrical and optical properties is the bandgap. Beyond graphene, recently discovered two-dimensional (2D) materials possess semiconducting bandgaps ranging from the terahertz and mid-infrared in bilayer graphene and black phosphorus, visible in transition metal dichalcogenide, to the ultraviolet in hexagonal boron nitride. In particular, these 2D materials were demonstrated to exhibit highly tunable bandgaps, achieved via the control of layers number, heterostructuring, strain engineering, chemical doping, alloying, intercalation, substrate engineering, as well as an external electric field. We provide a review of the basic physical principles of these various techniques on the engineering of quasi-particle and optical bandgaps, their bandgap tuneability, potentials and limitations in practical realization in future 2D device technologies.

What are attoseconds? Nobel-winning physics explained

by Daniel Lawler and Juliette Collen (from phys.org)

French physicist Anne L'Huillier was the first to discover a tool to pry open the world of attoseconds
French physicist Anne L’Huillier was the first to discover a tool to pry open the world of attoseconds.

The Nobel Physics Prize was awarded on Tuesday to three scientists for their work on attoseconds, which are almost unimaginably short periods of time.

Their work using lasers gives scientists a tool to observe and possibly even manipulate electrons, which could spur breakthroughs in fields such as electronics and chemistry, experts told AFP.

How fast are attoseconds?

Attoseconds are a billionth of a billionth of a second.

To give a little perspective, there are around as many attoseconds in a single second as there have been seconds in the 13.8-billion year history of the universe.

Hans Jakob Woerner, a researcher at the Swiss university ETH Zurich, told AFP that attoseconds are “the shortest timescales we can measure directly”.

Why do we need such speed?

Being able to operate on this timescale is important because these are the speeds at which electrons—key parts of an atom—operate.

For example, it takes electrons 150 attoseconds to go around the nucleus of a hydrogen atom.

This means the study of attoseconds has given scientists access to a fundamental process that was previously out of reach.

All electronics are mediated by the motion of electrons—and the current “speed limit” is nanoseconds, Woerner said.

If microprocessors were switched to attoseconds, it could be possible to “process information a billion times faster,” he added.

Graphic explaining discoveries made by the winners of the 2023 Nobel Prize for physics
Graphic explaining discoveries made by the winners of the 2023 Nobel Prize for physics.

How do you measure them?

Franco-Swede physicist Anne L’Huillier, one of the three new Nobel laureates, was the first to discover a tool to pry open the world of attoseconds.

It involves using high-powered lasers to produce pulses of light for incredibly short periods.

Franck Lepine, a researcher at France’s Institute of Light and Matter who has worked with L’Huillier, told AFP it was like “cinema created for electrons”.

He compared it to the work of pioneering French filmmakers the Lumiere brothers, “who cut up a scene by taking successive photos”.

John Tisch, a laser physics professor at Imperial College London, said that it was “like an incredibly fast, pulse-of-light device that we can then shine on materials to get information about their response on that timescale”.

How low can we go?

All three of Tuesday’s laureates at one point held the record for shortest pulse of light.

In 2001, French scientist Pierre Agostini’s team managed to flash a pulse that lasted just 250 attoseconds.

L’Huillier’s group beat that with 170 attoseconds in 2003.

In 2008, Hungarian-Austrian physicist Ferenc Krausz more than halved that number with an 80-attosecond pulse.

Hungarian-Austrian physicist Ferenc Krausz was among the new Nobel physics winners
Hungarian-Austrian physicist Ferenc Krausz was among the new Nobel physics winners.

The current holder of the Guinness World Record for “shortest pulse of light” is Woerner’s team, with a time of 43 attoseconds.

The time could go as low as a few attoseconds using current technology, Woerner estimated. But he added that this would be pushing it.

What could the future hold?

Technology taking advantage of attoseconds has largely yet to enter the mainstream, but the future looks bright, the experts said.

So far, scientists have mostly only been able to use attoseconds to observe electrons.

“But what is basically untouched yet—or is just really beginning to be possible—is to control” the electrons, to manipulate their motion, Woerner said.

This could lead to far faster electronics as well as potentially spark a revolution in chemistry.

“We would not be limited to what molecules naturally do,” but instead could “tailor them according to need,” Woerner said.

So-called “attochemistry” could lead to more efficient solar cells, or even the use of light energy to produce clean fuels, he added.

Lightmatter’s Mars Chip Performs Neural-Network Calculations at the Speed of Light MIT spinoff harnesses optical computing to make neural-networks run faster and more efficiently

Well, another contender has just entered the arena, one based on an entirely different paradigm: computing with light. A MIT spinoff called Lightmatter described its “Mars” device at last week’s Hot Chips virtual conference. Lightmatter is not the only company pursuing this novel strategy, but it seems to be ahead of its competition.

It’s somewhat misleading, though, for me to call this approach “novel.” Optical computing, in fact, has a long history. It was used as far back as the late 1950s, to process some of the first synthetic-aperture radar (SAR) images, which were constructed at a time when digital computers were not up to the task of carrying out the necessary mathematical calculations. The lack of suitable digital computers back in the day explains why engineers built analog computers of various kinds, ones based on spinning disks, sloshing fluids, continuous amounts of electric charge, or even light.

Over the decades, researchers have from time to time resurrected the idea of computing things with light, but the concept hasn’t proven widely practical for anything. Lightmatter is trying to change that now when it comes to neural-network calculations. Its Mars device has at its heart a chip that includes an analog optical processor, designed specifically to perform the mathematical operations that are fundamental to neural networks.

The key operations here are matrix multiplications, which consist of multiplying pairs of numbers and adding up the results. That you can perform addition with light isn’t surprising, given that the electromagnetic waves that constitute light add together when two light beams are combined.

What’s trickier to understand is how you can do multiplication using light. Let’s me sketch that out here, although for a fuller account I’d recommend reading the very nice description of its technology that Lightmatter has provided on its blog.

The basic unit of Lightmatter’s optical processor is what’s known as a Mach-Zehnder interferometer. Ludwig Mach and Ludwig Zehnder invented this device in the 1890s, so we’re not talking about something exactly modern here. What’s new is the notion of shrinking many Mach-Zehnder interferometers down to a size that’s measured in nanometers and integrating them together on one chip for the purpose of speeding up neural-network calculations.

Such an interferometer splits incoming light into two beams, which then take two different paths. The resulting two beams are then recombined. If the two paths are identical, the output looks just like the input. If, however, one of the two beams must travel farther than the other or is slowed, it falls out of phase with the other beam. At an extreme, it can be a full 180 degrees (one half wavelength) out of phase, in which case the two beams interfere destructively when recombined, and the output is entirely nulled.

More generally, the field amplitude of the light at the output will be the amplitude of the light at the input times the cosine of half of the phase difference between the light traveling in its two arms. If you can control that phase difference in some convenient way, you then have a device that works for multiplication.

Lightmatter’s tiny Mach-Zehnder interferometers are constructed by fashioning appropriately small waveguides for light inside a nanophotonic chip. By using materials whose refractive index depends on the electric field they are subjected to, the relative phase of the split beam can be controlled simply by applying a voltage to create an electric field, as happens when you charge a capacitor. In Lightmatter’s chip, that’s done by applying an electric field of one polarity to one arm of the interferometer and an electric field of the opposite polarity to the other arm.

As is true for a capacitor, current flows only while charge is being built up. Once there is sufficient charge to provide an electric field of the desired strength, no more current flows and thus no more energy is required. That’s important here, because it means that once you have set the value of the multiplier you want to apply, no more energy is needed if that value (a “weight” in the neural-network calculation) doesn’t subsequently change. The flow of light through the chip similarly doesn’t consume energy. So you have here a very efficient system for performing multiplication, one that operates at, well, the speed of light.

One of the weaknesses of analog computers of all kinds has been the limited accuracy of the calculations they can perform. That, too, is a shortcoming of Lightmatter’s chip—you just can’t specify numbers with as fine resolution as you can do using a digital circuitry. Fortunately, the “inference” calculations that neural networks carry out once they have been trained don’t need much resolution. Training a neural network, however, does. “Training requires higher dynamic range; we’re focused on inference because of that,” says Nicholas Harris, Lightmatter’s CEO and one of the company’s founders. “We have an 8-bit-equivalent system.”

You might imagine that Lightmatter’s revolutionary new equipment for performing neural-network calculations with light is at this stage just a laboratory prototype, but that would be a mistake. The company is quite far along in producing a practical product, one that can be added to any server motherboard with a PCI Express slot and immediately programmed to start cranking out neural-network inference calculations. “We are very focused on making it so that it doesn’t look like alien technology,” says Harris. He explains that Lightmatter not only has this hardware built, it has also created the necessary software toolchains to support its use with standard neural-network frameworks (TensorFlow and PyTorch).

Lightmatter expects to go into production with a commercial unit based its Mars device in late 2021. Harris says that the company’s chips, sophisticated as they are, have good yields, in large part because the nanophotonic components involved are not really that small compared with what’s found in cutting-edge electronic devices. “You don’t get the same point defects that destroy things.” So it shouldn’t be difficult to keep yields high and the pricing for the Mars device low enough to be competitive with GPUs.

And who knows, perhaps other companies such as Lightintelligence, LightOn, Optalysis, or Fathom Computing, will introduce their own light-based neural-network accelerator cards by then. Harris isn’t worried about that, though, he says. “I’d say we’re pretty far ahead.”
